Description：
Our gate valves are made of 304 stainless steel, which is strong and wear-resistant, more durable than iron, iron-plated and copper products, and does not rust.
Thickened 304 stainless steel is heavier, more resistant to high pressure, and stronger. Moreover, it is designed with the principle of hard sealing, NPT threaded interface, wear-resistant, high-temperature resistant, and durable. These stainless steel gate valve fittings can withstand high temperatures and long-term wear and tear.
Product Specifications：
| Process： | Investment Casting |
| Material: | Stainless Steel 304, 316, 1.4308, 1.4408, CF8, CF8M |
| Connection： | NPT, BSP, BSPT, etc. |
| Thread: | ASME B1.20.1 , BS21.0 , DIN2999/259 , ISO228-1 , JIS B 0203 , ISO7/1 |
| Size: | 1/8" to 4" (DN6 to DN100) |
| Pressure: | 1000PSI/1000WOG |
| Working Temperature: | -4°F – 300°F |
| Medium： | Water, Oil, Gas etc |
| Inspection Testing: | API598, EN12266（100% individually tested ） |
Application：
Stainless steel gate valve is used to complete the pipeline connection work and control the flow rate of water, air, kerosene and other media. Moreover, the stainless steel gate valve will provide a quick connection for pipe-to-pipe and pipe-to-pipe, solving the problem of media flow on and off.
Application：
Water | Oil | Gas |
| Chemical Processing | Pharmaceutical Industry | HVAC Systems |
| Marine and Coastal Applications | Fire Protection Systems | Other pipe systems |
Certificate：
Package：
